- Place of Origin: Zhejiang China
- Brand Name: jiequ
- Model Number: CBD15
- Weight: 285.000 kg
Model | CBD15 | |
Capacity(kg) | 610 | |
Moving type | Semi-electric | |
Min. distance to the ground (mm) | 85 | |
Max height(mm) | 205 | |
Length(mm) | 1150/1200 | |
Min turning radius (mm) | 1400 | |
Max walking speed(km/h) | Full-load | 3.5 |
No-live load | 4 | |
Max rise speed(mm/s) | Full-load | 56 |
No-live load | 60 | |
Max fall speed(mm/s) | Full-load | 57 |
No-live load | 59 | |
Driving motor(kw) | 0.6 | |
Rising motor(kw) | 0.8 | |
Battery(v/ah) | 24 | |
Net weight(kg) | 285 | |
- Place of Origin: Zhejiang China
- Brand Name: jiequ
- Model Number: CBD15
- Weight: 285.000 kg
Model | CBD15 | |
Capacity(kg) | 610 | |
Moving type | Semi-electric | |
Min. distance to the ground (mm) | 85 | |
Max height(mm) | 205 | |
Length(mm) | 1150/1200 | |
Min turning radius (mm) | 1400 | |
Max walking speed(km/h) | Full-load | 3.5 |
No-live load | 4 | |
Max rise speed(mm/s) | Full-load | 56 |
No-live load | 60 | |
Max fall speed(mm/s) | Full-load | 57 |
No-live load | 59 | |
Driving motor(kw) | 0.6 | |
Rising motor(kw) | 0.8 | |
Battery(v/ah) | 24 | |
Net weight(kg) | 285 | |
